50 / 60 Hz Water Injected Oil Free Air Compressor

As one of the water injected compressor manufacturers, suppliers, and exporters of mechanical products, We offer water injected compressors and many other products.

Please get in touch with us for details.

Mail:[email protected]

Water Injected Compressor

ep-water-injected-compressor-2bacj

Water injection compressors are a type of centrifugal compressor that uses water injection to cool and lubricate the compressor's bearings and seals. This helps to extend the life of the compressor and improve its efficiency. Water injection compressors are used in a variety of industries, including oil and gas, chemical processing, and power generation.

Water Injected Compressor Technical Parameters

Model Maximum working
pressure		 Capacity(FAD)* Installed motor
power		 Noise
Level**		 Dimensions
(mm)		 Weight Air Outlet
Pipe Diameter
50 Hz 60 Hz
bar(e) psig m3/min cfm m3/min cfm kW hp dB(A) L W H kG
15 7.5 109 2 71 1.48 52 15 20 63 1200 900 1200 650 G1"
8.5 123 1.94 69 1.46 52 15 20 63 1600 1100 1500 650 G1"
10.5 152 1.66 59 1.42 50 15 20 63 1200 900 1200 650 G1"
18 7.5 109 2.81 99 2.4 85 18.5 25 66 1600 1100 1500 800 G1"
8.5 123 2.7 95 2.33 82 18.5 25 66 1600 1100 1500 800 G1"
10.5 152 2.19 77 1.99 70 18.5 25 66 1600 1100 1500 800 G1"
22 7.5 109 3.48 123 3.37 119 22 30 66 1600 1100 1500 850 G1"
8.5 123 3.46 122 3.24 114 22 30 66 1600 1100 1500 850 G1"
10.5 152 2.73 96 2.63 93 22 30 66 1600 1100 1500 850 G1"
30 7.5 109 5.27 186 4.18 148 30 40 69 1600 1100 1500 920 G1-1/2"
8.5 123 5.15 182 4.15 147 30 40 69 1600 1100 1500 920 G1-1/2"
10.5 152 3.55 125 3.28 116 30 40 69 1600 1100 1500 920 G1-1/2"
D37 7.5 109 6.5 229 6.33 223 37 50 69 1600 1100 1500 950 G1-1/2"
8.5 123 6.26 221 6.18 218 37 50 69 1600 1100 1500 950 G1-1/2"
10.5 152 5.21 184 4.26 151 37 50 69 1600 1100 1500 950 G1-1/2"
45 7.5 109 8.2 289 7.8 275 45 60 69 2200 1400 1800 1700 DN50
8.5 123 7.81 276 7.51 265 45 60 69 2200 1400 1800 1700 DN50
10.5 152 6.23 220 6.25 221 45 60 69 2200 1400 1800 1700 DN50
45W 7.5 109 8.2 289 7.8 275 45 60 66 2200 1400 1800 1500 DN50
8.5 123 7.81 276 7.51 265 45 60 66 2200 1400 1800 1500 DN50
10.5 152 6.23 220 6.25 221 45 60 66 2200 1400 1800 1500 DN50
55 7.5 109 9.32 329 7.8 347 55 75 69 2200 1400 1800 1800 DN50
8.5 123 8.86 313 7.51 331 55 75 69 2200 1400 1800 1800 DN50
10.5 152 7.78 275 6.25 264 55 75 69 2200 1400 1800 1800 DN50
55W 7.5 109 9.32 329 9.84 347 55 75 66 2200 1400 1800 1800 DN50
8.5 123 8.86 313 9.37 331 55 75 66 2200 1400 1800 1800 DN50
10.5 152 7.78 275 7.48 264 55 75 66 2200 1400 1800 1800 DN50
75 7.5 109 12.41 438 11.19 395 75 100 73 2350 1400 1800 1800 DN50
8.5 123 12.39 438 10.63 375 75 100 73 2350 1400 1800 1800 DN50
10.5 152 10.45 369 9.33 330 75 100 73 2350 1400 1800 1800 DN50
75W 7.5 109 12.41 438 11.19 395 75 100 71 2200 1400 1800 1800 DN50
8.5 123 12.39 438 10.63 375 75 100 71 2200 1400 1800 1800 DN50
10.5 152 10.45 369 9.33 330 75 100 71 2200 1400 1800 1800 DN50
90W 7.5 109 16.48 582 15.39 543 90 120 73 2400 1700 1800 1800 DN65
8.5 123 16.36 578 15.24 538 90 120 73 2400 1700 1800 1800 DN65
10.5 152 12.82 453 12.52 442 90 120 73 2400 1700 1800 1800 DN65
110W 7.5 109 20.45 722 19.78 698 110 150 73 2400 1700 1800 1800 DN65
8.5 123 19.82 100 19.63 693 110 150 73 2400 1700 1800 1800 DN65
10.5 152 15.55 549 15.35 542 110 150 73 2400 1700 1800 1800 DN65
132W 7.5 109 21.99 776 24.53 886 132 175 76 2400 1700 1800 1800 DN65
8.5 123 21.94 775 23.78 840 132 175 76 2400 1700 1800 1800 DN65
10.5 152 19.79 699 18.66 659 132 175 76 2400 1700 1800 1800 DN65

Water Injected Compressor Features

Increased efficiency: Water injection compressors can be up to 10% more efficient than traditional compressors.

Extended life: Water injection compressors can last up to twice as long as traditional compressors.

Reduced maintenance: Water injection compressors require less maintenance than traditional compressors.

Improved safety: Water injection compressors are safer to operate than traditional compressors.

We are one of the best water injected compressor suppliers. Due to our excellent product quality and after-sales service, we have exported our products to clients all over the world and won a good reputation. Welcome customers at home and abroad to contact us, negotiate business, exchange information, and cooperate with us!
